Description
Classic Hi-Fi Sound. Modern Connectivity.
Experience powerful, versatile home audio with the AIWA AMU-120BT 120W Bluetooth Stereo Amplifier. Combining classic Hi-Fi performance with modern wireless and digital connectivity, this amplifier is designed to give you complete control over your music.
With 120W total RMS output (2 × 60W RMS), Bluetooth 5.0, USB and SD MP3 playback, dedicated Phono input for turntables, multiple analogue inputs, microphone connectivity and A/B speaker selection, the AMU-120BT is built to handle a wide range of audio sources.
Whether you're streaming music from your smartphone, playing your vinyl collection, connecting a CD player or using USB/SD media, the AIWA AMU-120BT provides a flexible and powerful central hub for your Hi-Fi system.
KEY FEATURES
- 120W Total RMS Power – 2 × 60W RMS output
- Bluetooth 5.0 with A2DP/AVRCP support
- Wireless Bluetooth range of up to 10 metres
- 7 analogue audio inputs
- Dedicated PHONO MM input for turntables
- Built-in Phono pre-amplifier with RIAA equalisation
- CD/SACD input
- 3 × AUX inputs
- Microphone input for karaoke and microphone applications
- USB port for MP3 playback
- SD card slot for MP3 playback
- USB/SD media support up to 128GB
- A/B/A+B speaker selection
- Quad speaker connections
- Independent Bass and Treble controls
- Bass and Treble adjustment up to ±10dB
- Loudness function for enhanced audio at lower listening levels
- EQ Bypass function for a more direct audio signal
- 16-character × 2-line dot-matrix display
- White LED backlighting with tinted prism lens
- Scrolling media information and ID3-tag information
- Full-function remote control
- 6.3mm headphone output
- RCA REC/LINE output
- High-quality Class A/B amplifier
- Rotary volume control
- Modern aluminium construction
- Stereo sound output
AUDIO PERFORMANCE
Output Power:
120W RMS total
2 × 60W RMS per channel
Frequency Response:
0Hz – 50kHz ±0.5dB @ AUX IN
Signal-to-Noise Ratio:
100dB (AUX input)
83dB (USB/SD-MP3 and Phono input)
Channel Separation:
80dB @ 1kHz
Total Harmonic Distortion:
0.005% @ 1kHz / 1W
0.01% @ 1kHz / 45W
Speaker Impedance:
A/B: 4–8Ω
A+B: 8Ω
Phono Input:
MM 3.3mV / 47kΩ
CONNECTIVITY
Wireless
- Bluetooth 5.0
- A2DP + AVRCP profiles
- Up to 10m wireless operating range
Audio Inputs
- PHONO MM
- CD/SACD
- AUX × 3
- Microphone
- Bluetooth
- USB
- SD Card
Audio Outputs
- Speaker outputs × 4
- A/B/A+B speaker selection
- RCA Line/REC Out
- 6.3mm stereo headphone output
USB & SD MP3 PLAYBACK
Play your digital music collection directly through the amplifier using a USB flash drive or SD memory card.
- MP3 playback
- USB Type-A port
- SD card slot
- Supports storage devices up to 128GB
- MP3 playback controls via front panel and remote control
- Scrolling ID3-tag/song information on the display
SOUND CONTROL
The AMU-120BT gives you detailed control over your listening experience:
- Bass adjustment: ±10dB
- Treble adjustment: ±10dB
- Loudness enhancement
- EQ Bypass
- Independent tone controls
- A/B speaker selection
- Stereo output
DISPLAY
The front panel features a clear 16-character × 2-line dot-matrix display with white LED backlighting.
The display provides useful information including source selection, playback information and scrolling media/ID3-tag information.
REMOTE CONTROL
The included full-function remote control allows convenient operation of the amplifier and connected media sources, including volume adjustment and USB/SD/Bluetooth playback controls.
DESIGN & BUILD
- Premium modern Hi-Fi design
- Aluminium construction
- Large rotary volume control
- Easy-access front-panel controls
- White LED illuminated display
- Available in Black and Silver finishes
TECHNICAL SPECIFICATIONS
| Specification | Details |
|---|---|
| Model | AIWA AMU-120BT |
| Product Type | Bluetooth Stereo Integrated Amplifier |
| Output Power | 120W RMS |
| Power per Channel | 2 × 60W RMS |
| Amplifier Class | A/B |
| Bluetooth | Version 5.0 |
| Bluetooth Profiles | A2DP + AVRCP |
| Bluetooth Range | Up to 10m |
| Frequency Response | 0Hz – 50kHz ±0.5dB @ AUX IN |
| Signal-to-Noise Ratio | >100dB AUX / >83dB USB-SD-MP3 & Phono |
| Channel Separation | >80dB @ 1kHz |
| THD | 0.005% @ 1kHz/1W; 0.01% @ 1kHz/45W |
| Speaker Impedance | 4–8Ω A/B; 8Ω A+B |
| Phono Input | MM 3.3mV / 47kΩ |
| USB | USB Type-A, MP3 playback |
| USB/SD Capacity | Up to 128GB |
| Headphone Output | 6.3mm stereo |
| Microphone Input | 6.3mm |
| Speaker Outputs | 4 |
| Display | 16-character × 2-line dot matrix |
| Tone Controls | Bass & Treble ±10dB |
| Speaker Selection | A / B / A+B |
| Power Supply | 230/240V AC, 50Hz |
| Dimensions | 430 × 100 × 292mm (W × H × D) |
| Dimensions | 43 × 10 × 29.2cm |
| Weight | 6.5kg |
WHAT'S INCLUDED
- 1 × AIWA AMU-120BT Stereo Amplifier
- 1 × Full-function Remote Control
- 2 × AIWA AAA Alkaline Batteries
- 1 × RCA to 3.5mm Stereo Cable – 1.5m
- 1 × RCA to RCA Stereo Cable – 1.2m
- Instruction Manual
- Reference Guide
- Warranty Sheet
- Declaration of Conformity
PERFECT FOR
The AIWA AMU-120BT is ideal for:
- Home Hi-Fi systems
- Vinyl and turntable setups
- Music streaming
- TV and media audio systems
- CD players and other analogue sources
- USB and SD music playback
- Multi-speaker setups
- Karaoke and microphone applications
- Living rooms, entertainment rooms and home audio systems
Powerful 120W Stereo Sound. Endless Ways to Listen.
From vinyl records and traditional Hi-Fi sources to wireless Bluetooth streaming and digital USB/SD playback, the AIWA AMU-120BT brings classic amplifier performance together with modern connectivity in one versatile system.
